Dimensions (lxwxh)2920x1417x1166 mm
Weight without driver217 kg
Track width f/r1194 mm / 1210 mm
Wheel base1540 mm
Aero partsfront and rearwing, undertray and side pods
Suspensiondouble unequal length A-arm, spring and damper connected via rocker, ARB
DamperKW Formula Student
Wheels/tires7×13 zoll with 205/470 Continental tires
Motors4x AMK DD5-14 synchronous motor
Coolingtwin side pod mounted radiators with thermostatic controlled electric fans
Power128 kW
Max rpm20 000 rpm
Motor controllersAMK ASYN KW26
Max system voltage600V
Battery cells288 LiPo
Max battery capacity7.05 kWh
Drivetrain4x two stage planetary gearboxes inside the wheel hubs
Drive ratio1:14
MiscellaneousHeadlight, live-telemetry-system
Driverlessfully integrated in electrical system
Driverless: Detectioncamera based detection
Driverless: HardwareJetson AGX Xavier
Wire harnesssplited in rear and front harness, driverless harness fully integrated
Control units9 seperate control units in different locations
